OneUp Components Wave Pedals
OneUp Components Wave Pedals

Additional Photos:
List Price: $199.99
Our Price: $184.99
You save $15.00


Free Shipping
Product Code: ONEUP25-WAVE-PEDAL

Choose Your Color
Click to view another Color - MAIN COLOR OPTIONS

Qty:
Description

Get ultimate grip and bike control with our innovative Wave profile.

Most flat pedal profiles are either convex or concave. Wave is a patented hybrid convex/concave shape that promotes an aggressive heels-dropped riding position and gives you a more natural pedal stroke when seated. With Wave, your foot is being held by the shape of the pedal - not just the pins.

It’s time to ride the Wave.

  • Convex + Concave = Wave: The front half of the pedal has a concave profile that hugs the ball of your foot for unmatched grip. The back half of the pedal is sloped to promote an aggressive heels-down foot position for more power and control.
  • Angled Pins: Because the Wave design naturally encourages your heels to drop, the pins are installed at an angle to be vertical when riding. This leverages the Wave profile and increases grip - without the need for longer pins.
  • DH-Rated Axle: The Wave pedal uses a proven axle, bushing and bearing configuration for improved reliability — strong enough for all types of riding.
  • 1 year manufacturer warranty.
Specs & Information
  • Weight: 355g (Pair)
  • Thickness: Axle 14.2mm / Edges 11.5mm
  • Size: 107mm x 110mm (W x L)
  • Bearing configuration: Inboard igus™ Bushing and 3x outboard cartridge bearings
  • Body: Forged and CNC’d 6061 Aluminum Body
  • Axle: Chromoly Steel with Black ED coating
  • Pins: M4 Hollow Pin 10 x pins per side (self-cleaning hex through hole)
  • Colours: Black, Red, Dark Green, Dark Blue, Orange, Purple, Grey, Bronze
  • 2x Wave Pedals (1x Left, 1x Right)
  • 9x Installed M4 hollow threaded pins per side (36x pins total)
  • 10x Spare/Uninstalled M4 hollow threaded pins
  • 1x Pedal Bearing Nut Tool
