Occam is an adjustable trail bike, ready for any adventure.
Adventure²
The no compromise trail machine. Whether you're chasing flow and speed or seeking out the roughest descents, there's an Occam for you.
Headset Adjust
The headset angle is easily adjustable using the offset headset cup. The possibility of regulating +/- 0.75 degrees allows you to slip into a more slack position for steeper tracks or more aggressive runs.
Lock on the Go
Remote lockout comes to trail bikes with Occam SL. Locking and unlocking the suspension quickly becomes second nature and once you have tried it you won't want to live without it.
LOCKR
Enjoy the advantages of our updated LOCKR with easier access than ever. Store tools, lunch or even a jacket easily behind the water bottle mount ready for easy access.
Second Skin
Occam is ready for a tough life and the replaceable vinyl protection helps keep the paintwork looking new for longer.
Fast Trail Suspension
140mm of travel front and rear, tuned for pedaling efficiency.
Carbon Shock Extender
The carbon shock extender maximizes rigidity and minimizes weight.
w/Neutral (0 degree) Head Angle S M L XL 1Seat Tube (C-T) 405 415 430 460 2Top Tube (EFF) 570 596 622 649 3Head Tube 95 100 110 120 4Chainstay 440 440 440 440 5BB Drop 37 37 37 37 6BB Height 341 341 341 341 7Wheelbase 1191 1218 1245 1276 8Head Angle 65,5 65,5 65,5 65,5 9Seat Angle 78 78 78 78 10RAKE 44 44 44 44 11Reach 440 465 490 515 12Stack 611 615 624 633 13Seatpost insertion MIN 554 554 554 554 14Fork Length 410 420 435 460
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Specs & Information
- Frameset
- Frame
- Orbea Occam Hydro. Concentric Boost 12x148 rear axle. Pure Trail geometry. Both Internal & External cable routing. Asymmetric design. 29" wheels. Linkage compatible with OC multitool
- Shock
- Fox Float Performance Remote Push-lock Evol custom tune 210x50mm
- Fork
- Marzocchi Bomber Z2 140 Rail Remote Push-Lock QR15x110
- Steerer tube
- FSA 1-1/2" Integrated Aluminium Cup
- Vinyl Frame Protector
- N/A
- Drivetrain
- Crankset
- Forged alloy, 32t
- Shifters
- Shimano Deore M6100
- Cassette
- Shimano CS-M6100 10-51t 12-Speed
- Rear derailleur
- Shimano Deore M6100 SGS Shadow Plus
- Chain
- Shimano M6100
- Cockpit
- Handlebar
- OC Mountain Control MC30, Rise20, Width 800
- Stem
- OC Mountain Control MC20, 0º
- Computer Mount
- N/A
- Brakes
- Brakes
- Shimano MT201 Hydraulic Disc
- Brakes Configuration
- N/A
- Wheels
- Wheels
- Alloy, Tubeless, 29", 29c, 32H
- Tyres
- Maxxis Dissector 2.40" 60TPI Rigid EXO/TR
- Tyres
- Maxxis Rekon 2.4" 60 TPI Rigid EXO/TR
- Components
- Seatpost
- OC Mountain Control MC22, 31.6mm, Dropper
- Saddle
- Selle Royal 2058 DRN
- Grips
- OC Lock On
- Remote lockout
- OC Squidlock MC20 Remote, Dropper, Suspension 2 Pos
- Accessories
- Storage
- Accesories Containers
- Tools
- N/A
|
|
|
|
|
|
|
