XDS X-LAB SP5+ City E-Bike 2026
XDS X-LAB SP5+ City E-Bike 2026

Additional Photos:
Our Price: $1,899.00


Free Shipping
Product Code: XDS26-SP5PLUS

Frame Size


Choose Your Color
Click to view another Color - MAIN COLOR OPTIONS

Qty:
Description Technical Specs Extended Information

Fitness-focused electric bike that amplifies your every move.

The SP5+ is built to make electric cycling simple, smooth, and accessible.

Its lightweight frame and intuitive electric assist provide effortless acceleration and reliable range, helping riders cover longer distances with ease.

Balanced geometry and durable construction ensure stability and comfort whether you're commuting, exploring your neighborhood, or enjoying weekend rides.

The SP5+ proves that electric mobility can be both practical and fun, with an element of fitness built in.
Specs & Information

    • Technical Specifications

      FRAME

      XDS X6 Alloy Frame, UDH Compatible

      FORK

      XDS Carbon Fork, 100x12mm Thru-axle

      HANDLEBAR / STEM

      Branta Alloy Integrated, w/ Display & Front Light, 680mm

      Width, 90mm Length, 6 Degree Rise, 9 Degree Backsweep

      SEATPOST

      XDS Alloy Seatpost, Aero Shape, 350mm Length

      REAR DERAILLEUR

      Shimano Cues RD-U4000, 9-Speed

      SHIFTER

      Shimano Cues 9-Speed

      BRAKES

      Branta EC215D Hydraulic E-Bike Brake, w/ Cutoff Switch, 3 Finger Lever,

      2 Piston Caliper

      CASSETTE

      Shimano CS-LG300 11-46T, 9-Speed

      CRANKSET

      Branta Alloy Crankset, 46T, Narrow-wide Teeth

      MOTOR

      XDS Mid-drive X800 Motor, 250 Watt Maximum Continuous Rated Power, 400 Watt Peak Power, 85Nm Peak Torque, Dual-sided Torque Sensor

      BATTERY

      XDS Rechargeable Li-ion Battery, 339Wh, LG Battery Cells, 3A Charger (0-100% 3hr 15min)

      E-BIKE SYSTEM

      UL2271 and UL2849 Certified, Range up to 50mi, Class 2 (Unlock to Class 3 via the X-Lab Bikes Mobile App), Pedal-assist and Throttle, Integrated F+R Lights (+ Brake Lights), Max Load 265 lbs (120 kg)

      CONNECTIVITY

      Apple Find My Anti-Theft Technology, Bluetooth, OTA Updates

      ROTORS

      Branta Z8, F:160mm R:160mm

      CHAIN

      KMC E-GLIDE-S

      WHEELSET

      Branta Alloy E-Bike Wheelset

      TIRES

      Branta R240, 700x40C, 30TPI

      SADDLE

      Branta SRX+

      PHONE HOLDER

      Quad Lock Mount

      WEIGHT

      16.79 kg / 37.01 lbs (Size L)

      SIZE OPTIONS

      S / M / L
