XDS X-LAB ST5+ City E-Bike 2026
XDS X-LAB ST5+ City E-Bike 2026

Additional Photos:
Our Price: $1,999.00


Free Shipping
Product Code: XDS26-ST5PLUS

Frame Size


Choose Your Color
Click to view another Color - MAIN COLOR OPTIONS

Qty:
Description Technical Specs Extended Information

Versatile electric bike for everyday riding, commuting, and convenience.

The ST5+ brings X-LAB engineering to modern urban mobility.

Powered by an integrated electric system and built on a refined aluminum platform, the ST5+ delivers smooth acceleration, confident handling, and the comfort needed for everyday riding.

Designed for riders who want more from their city bike, the ST5+ makes commuting faster, cleaner, and far more enjoyable.

From daily travel to spontaneous detours, the ST5+ transforms the way you move through the city.
Specs & Information

    • Technical Specifications

      FRAME

      XDS X6 Alloy Frame, UDH Compatible

      FORK

      XDS Suspension Fork, Coil Spring, 80mm Travel,

      110x15mm Thru-axle

      HANDLEBAR / STEM

      Branta Alloy Integrated, w/ Display & Front light, 680mm

      Width, 90mm Length, 6 Degree Rise, 15 Degree Backsweep

      SEATPOST

      XDS 31.6mm Alloy Seatpost , 350mm Length

      REAR DERAILLEUR

      Shimano Cues RD-U4000, 9-Speed

      SHIFTER

      Shimano Cues 9-Speed

      BRAKES

      Branta EC4D Hydraulic E-Bike Brake, w/ Cutoff Switch, 3 Finger Lever,

      4 Piston Caliper

      CASSETTE

      Shimano CS-LG300 11-46T, 9-Speed

      CRANKSET

      Branta Alloy Crankset, 46T, Narrow-wide Teeth

      MOTOR

      XDS Mid-drive X800 Motor, 250 Watt Maximum Continuous

      Rated Power, 470 Watt Peak Power, 95Nm Peak Torque, Dual-sided Torque Sensor

      BATTERY

      XDS Rechargeable Li-ion Battery, 619Wh, LG Battery Cells, 3A Charger (0-100% 5hr)

      E-BIKE SYSTEM

      UL2271 and UL2849 Certified, Range up to 80mi, Class 2 (Unlock to Class 3 via the X-Lab Bikes Mobile App), Pedal-assist and Throttle, Integrated F+R Lights (+ Brake Lights), Max Load 330 lbs (150 kg)

      CONNECTIVITY

      Apple Find My Anti-Theft Technology, Bluetooth, OTA Updates

      ROTORS

      Branta PN28, F:180mm R:180mm

      CHAIN

      KMC E-GLIDE-S

      WHEELSET

      Branta Alloy E-Bike Wheelset

      TIRES

      CST CTC-06, 27.5’’x2.4, 30TPI, w/ Reflective Stripe

      SADDLE

      Branta C301

      PHONE HOLDER

      Quad Lock Mount

      REAR RACK

      MIK-HD Rack

      WEIGHT

      24.76 kg / 54.58 lbs (Size L)

      SIZE OPTIONS

      M / L
