XDS X-LAB ST5+ LS City E-Bike 2026
XDS X-LAB ST5+ LS City E-Bike 2026

Additional Photos:
Our Price: $1,999.00


Free Shipping
Product Code: XDS26-ST5PLUS-LS

Choose Your Color
Click to view another Color - MAIN COLOR OPTIONS
Frame Size



Qty:
Description Technical Specs Extended Information

Versatile electric bike for everyday riding, commuting, and convenience.

The ST5+ LS brings X-LAB engineering to modern urban mobility.

Powered by an integrated electric system and built on a refined aluminum platform, the ST5+ LS delivers smooth acceleration, confident handling, and the comfort needed for everyday riding.

Designed for riders who want more from their city bike, the ST5+ LS makes commuting faster, cleaner, and far more enjoyable.

From daily travel to spontaneous detours, the ST5+ LS transforms the way you move through the city.
Specs & Information

    • Technical Specifications

      FRAME

      XDS X6 Aluminum Frame, UDH Compatible

      FORK

      XDS Suspension Fork, Coil Spring, 80mm Travel,

      110x15mm Thru-axle

      HANDLEBAR / STEM

      Branta Aluminum Integrated, w/ Monitor & Front light, 680mm

      Width, 90mm Length, 8 Degree Rise, 28 Degree Backsweep

      SEATPOST

      XDS Aluminum Seatpost, 31.6mm

      REAR DERAILLEUR

      Shimano Cues RD-U4000, 9-Speed

      SHIFTER

      Shimano Cues SL-U4000-9R

      BRAKES

      Branta E-Bike Brake, w/ Cutoff Switch, 3 Finger Lever,

      4 Pistons Caliper

      CASSETTE

      Shimano CS-LG300 11-46T, 9-Speed

      CRANKSET

      Branta Aluminum Crankset, 46T, Narrow-wide Teeth

      MOTOR

      XDS Mid-drive X800 Motor, 250 Watt Maximum Continuous

      Rated Power, 470 Watt Peak Power, 85N.m. Peak Torque

      BATTERY

      XDS Rechargeable Li-ion Battery, 619Wh

      ROTORS

      Branta 180Z, F:180mm R:180mm

      CHAIN

      KMC E-GLIDE-S

      WHEELSET

      Branta Aluminum E-Bike Wheelset

      TIRES

      CST CTC-06, 27.5"x2.4, 30TPI, w/ Reflective Strips

      SADDLE

      Branta C302

      PHONE HOLDER

      Quad Lock Mount

      REAR RACK

      MIK-HD Rack

      WEIGHT

      26kg / 57.32 (Size M)

      *Continuous Product Improvement

      Innovation never stands still. As part of our commitment to building the best possible bicycles, X-LAB reserves the right to update specifications, components, colors, and other product details at any time without notice. We make every effort to keep our published specifications current, but minor variations may occur between production batches. Please contact your local X-LAB dealer or Customer Support if you would like to confirm the latest specifications before purchase.
